Battery Power Conversion System (PCS) 15kW | 25kW | 30kW | 40kW | 50kW | 60kW
This battery power conversion system converts energy between a compatible DC battery bank and the AC side of an energy storage installation. Select the kW option to match load demand, then check the DC voltage window and BMS/EMS interface for that exact model. AC power rating, battery energy and PV input are separate design limits. Solar input and backup arrangements require confirmation in the project wiring diagram. Warranty: 5 years.
Battery, inverter, PV panel, and accessory availability is confirmed within 24 hours by city, quantity, and project configuration.
Key Features
- Conversion efficiency >97%
- High voltage HV battery 200-850V, compatible with 280/314Ah cells
- 3-phase 400V, supports parallel connection of multiple units
- Fast on/off grid switching <15ms
- Supports combined operation with diesel generators
- Suitable for villas, factories, small islands, farms
Technical Specifications
| 15kW | 25kW | 30kW | 40kW | 50kW | 60kW | |
|---|---|---|---|---|---|---|
| Power | 15kW / 15kVA | 25kW / 25kVA | 30kW / 30kVA | 40kW / 40kVA | 50kW / 50kVA | 60kW / 60kVA |
| Maximum AC current | 22A | 36A | 43.5A | 57.7A | 72.1A | 87A |
| Maximum battery current | 85A | 80A | 100A | 120A | 150A | 180A |
| Off-grid power capacity | 15kVA | 27.5kVA | 30kVA | 40kVA | 50kVA | 60kVA |
| Dimensions | 540×430×170 mm | 540×430×170 mm | 540×430×170 mm | 600×600×900 mm | 600×600×900 mm | 600×600×900 mm |
| Weight | 35 kg | 38 kg | 40 kg | 90 kg | 95 kg | 100 kg |
| Warranty | 5 years | 5 years | 5 years | 5 years | 5 years | 5 years |
| MPPT | - | - | - | 2 channels, PV up to 40kW | 2 channels, PV up to 50kW | 2 channels, PV up to 60kW |
| Type | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) |
| Battery voltage | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC |
| AC grid | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz |
| Efficiency | >97% | >97% | >97% | >97% | >97% | >97% |
| On/off grid switching | <15ms | <15ms | <15ms | <15ms | <15ms | <15ms |
| Parallel | Supports multiple units in parallel | Supports multiple units in parallel | Supports multiple units in parallel | Supports multiple units in parallel | Supports multiple units in parallel | Supports multiple units in parallel |
| Communication | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN |
| Temperature | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C |
| Cooling | Forced air cooling fan | Forced air cooling fan | Forced air cooling fan | Forced air cooling fan | Forced air cooling fan | Forced air cooling fan |
Compatible Batteries
FAQ
What is the warranty for Battery Power Conversion System (PCS) 15kW | 25kW | 30kW | 40kW | 50kW | 60kW?▼
Battery Power Conversion System (PCS) 15kW | 25kW | 30kW | 40kW | 50kW | 60kW comes with a 5 years warranty from Batelithium. We provide full technical support throughout the warranty period.
