51.2V Rack Mount LiFePO4 Battery for Solar Storage 50Ah | 100Ah | 200Ah | 314Ah
This 51.2V rack mount LiFePO4 battery series is intended for a compatible solar battery rack or cabinet. The rack format allows equipment to be organised with accessible terminals and communication wiring. Match the selected Ah option to inverter demand, then verify the supported BMS protocol, firmware and parallel configuration. CAN or RS485 connectors do not by themselves confirm inverter compatibility. Warranty: 7 years · 8000 cycles.
Battery, inverter, PV panel, and accessory availability is confirmed within 24 hours by city, quantity, and project configuration.
Key Features
- Standard 19" rack design, flexible stacking
- Up to 16 units in parallel, easy expansion
- Smart BMS with full protection
- Compatible with multiple inverters (PYLON, DEYE, GROWATT...)
- Flexible RS485/RS232/CAN communication
Technical Specifications
| 50Ah | 100Ah | 200Ah | 314Ah | |
|---|---|---|---|---|
| Capacity | 50Ah / 2560Wh | 100Ah / 5120Wh | 200Ah / 10240Wh | 314Ah / 16077Wh |
| Charge/discharge current | 5A ~ 50A | 10A ~ 100A | 20A ~ 200A | 30A ~ 200A |
| Dimensions (W×D×H) | 350×270×170 mm | 399×450×260 mm | 590×380×260 mm | 590×410×260 mm |
| Weight | 25 kg | 43.5 kg | 87.5 kg | 127 kg |
| Warranty | 7 years | 7 years | 7 years | 7 years |
| Charge cycles | 8000 cycles | 8000 cycles | 8000 cycles | 8000 cycles |
| Nominal voltage | 51.2V | 51.2V | 51.2V | 51.2V |
| Battery type | LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 |
| Maximum charge voltage | 58.4V | 58.4V | 58.4V | 58.4V |
| Minimum discharge voltage | 40V | 40V | 40V | 40V |
| Operating temperature | -20°C ~ 60°C | -20°C ~ 60°C | -20°C ~ 60°C | -20°C ~ 60°C |
| BMS | Charge/Discharge/Short circuit/Temperature/Balancing | Charge/Discharge/Short circuit/Temperature/Balancing | Charge/Discharge/Short circuit/Temperature/Balancing | Charge/Discharge/Short circuit/Temperature/Balancing |
| Communication | RS485, RS232, CAN | RS485, RS232, CAN | RS485, RS232, CAN | RS485, RS232, CAN |
| Inverter compatibility | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO | PYLON, DEYE, GROWATT, GOODWE, SOLAX, LUXPOWER, MUST, SRNE, MEGAREVO |
| Maximum parallel units | 16 units | 16 units | 16 units | 16 units |
| Certifications | CE, RoHS | CE, RoHS | CE, RoHS | CE, RoHS |
FAQ
What is the warranty for 51.2V Rack Mount LiFePO4 Battery for Solar Storage 50Ah | 100Ah | 200Ah | 314Ah?▼
51.2V Rack Mount LiFePO4 Battery for Solar Storage 50Ah | 100Ah | 200Ah | 314Ah comes with a 7 years warranty from Batelithium. We provide full technical support throughout the warranty period.
Do you ship internationally?▼
Batelithium ships worldwide. Free shipping for bulk orders. Contact our team for a custom quote.
